Titanium Plate & Sheet
Cold-rolled and hot-rolled titanium plate and sheet, 0.3–60 mm thick, quoted to ASTM B265 / ASME SB265 in commercially pure Gr1–Gr4 and alloy Gr5, Gr7, Gr9, Gr12 and Gr23. Sawing, waterjet and laser cut-to-size from Baoji mills, with mill test certificates.
Specification Table
| Item | Range / Condition |
|---|---|
| Thickness | 0.3 – 60 mm (foil below 0.3 mm on the coil & foil page) |
| Width | 30 – 1500 mm |
| Length | 50 – 6000 mm, or cut-to-size |
| Grades | Gr1 · Gr2 · Gr3 · Gr4 · Gr5 · Gr7 · Gr9 · Gr12 · Gr23 |
| Condition | Annealed (M) standard; solution-treated & aged for Gr5 on request |
| Surface | Mill / pickled; polished to Ra 0.4–3.2 on request |
| Tolerance | Per the specified standard revision — tell us which edition you buy to |
| Packing | Moisture-proof wrap, palletised or wooden case for ocean freight |
| Grade | Typical t × w | Note |
|---|---|---|
| Gr2 (TA2) | 1.0–3.0 × 1000–1500 mm | Chemical & marine sheet |
| Gr2 | 2.0 × 1000 × 2000 mm | One of the most-requested cut blanks |
| Gr5 (TC4) | 3.0–25 × 500–1200 mm | Machining and fabrication stock |
| Gr1 | 0.5–1.5 mm deep-drawing | Forming applications |
Standards We Quote To
ASTM B265 and ASME SB265 (plate/sheet scope and naming), AMS 4911 for Gr5 sheet where specified, GB/T 3621 for domestic-standard orders. Revision and edition per your purchase spec.
Cut-to-Size Service
Full mill sheets are not the only way to buy titanium. We cut to your size list by bandsaw, waterjet or laser — you pay for the pieces you weld, not the sheet you don't. Typical patterns ordered: 1000×2000 mm blanks, reactor segment nesting, and single custom plates for repair jobs.
Applications
Plate feeds chemical reactors and columns, tube-sheet blanks for heat exchangers, and seawater systems on marine projects. For thin foil and strip see coil & foil.
Documentation
Every shipment carries a mill test certificate (MTC, EN 10204 3.1 style) with heat number traceability. How MTCs work →
